HDPE Uniaxial Geogrid for Road & Slope Reinforcement
1. High uniaxial tensile strength, good creep resistance, and stable chemical properties
2. High coefficient of friction with sand and gravel.
Applications:
1. Suitable for roadbed reinforcement of highways, municipal roads, railways, airport runways, etc.
2. Suitable for dam reinforcement of rivers and sea dikes.
3. Suitable for fencing of orchards, vegetable gardens, livestock areas, land, etc., safe and convenient to use, easy to assemble and disassemble, and aesthetically pleasing.
4. Suitable for reinforcement projects of reinforced soil retaining walls along highways, municipal roads, railways, airport runways, rivers, and coastlines.
Product Specifications and Performance Parameters
PP/hdpe Uniaxial Stretch Geogrid Technical Parameters
| Item / Specification | Unit | WW-35 | WW-50 | WW-80 | WW-120 | WW-160 | WW-200 |
|---|---|---|---|---|---|---|---|
| Tensile Strength per Meter Width | kN/m≥ | 35 | 50 | 80 | 120 | 160 | 200 |
| Elongation at Break | %≤ | 10 | |||||
| Tensile Strength at 2% Elongation | kN/m≥ | 10 | 12 | 26 | 36 | 45 | 56 |
| Tensile Strength at 5% Elongation | kN/m≥ | 22 | 28 | 48 | 72 | 90 | 112 |
| Ultimate Junction Strength | kN/m≥ | 15 | 21 | 30.2 | 41 | 49 | 64 |
PE Uniaxial Stretch Geogrid Technical Parameters
| Item / Specification | Unit | WW-35 | WW-50 | WW-80 | WW-120 | WW-160 |
|---|---|---|---|---|---|---|
| Tensile Strength per Meter Width | kN/m≥ | 35 | 50 | 80 | 120 | 160 |
| Elongation at Break | %≤ | 11.5 | ||||
| Tensile Strength at 2% Elongation | kN/m≥ | 7.5 | 12 | 21 | 33 | 47 |
| Tensile Strength at 5% Elongation | kN/m≥ | 21.5 | 23 | 40 | 65 | 93 |
| Ultimate Junction Strength | kN/m≥ | 16 | 21 | 31 | 46 | 60 |
Tip: Special specifications will be produced according to contract or agreement requirements.
Construction methods
- When used in roadbeds, the construction method is the same as that for biaxial geogrids.
- When used in reinforced soil retaining walls, the construction method is as follows:
1. Set up the foundation and construct according to the designed wall system. When using precast reinforced concrete panels, they are generally 12-15cm thick and supported on a precast concrete foundation. The width should not exceed 30cm, the thickness should not be less than 20cm, and the embedment depth should not be less than 60cm to prevent the effects of frost heave.
2. Level the wall foundation. Excavate and level according to design requirements. Soft soil needs to be compacted or replaced, compacted to the required density, slightly exceeding the wall surface area.
3. Lay the reinforcement. The main strength direction of the reinforcement should be perpendicular to the wall surface and fixed with pins.
4. Backfill the wall. Use mechanical backfilling, maintaining a distance of at least 15cm between the wheels and the reinforcement. After compaction, each layer of soil should be approximately 15cm thick.
5. During wall construction, geotextile should be wrapped around the wall surface to prevent soil loss.
WEIWO-Your Best Geogrid Supplier
As a professional geosynthetic manufacturer, we supply HDPE uniaxial geogrids for infrastructure projects worldwide.
Our advantages include:
- Stable production capacity
- Strict quality control system
- Competitive factory price
- Fast delivery for bulk orders
Every batch of products is tested to ensure consistent tensile strength and durability.
What is the difference between uniaxial and biaxial geogrid?
Uniaxial geogrids provide high tensile strength in one direction, mainly used for retaining walls and slopes, while biaxial geogrids provide strength in two directions, commonly used for road base reinforcement.
How to choose the right tensile strength?
The required strength depends on wall height, soil type, and load conditions. Our engineers can recommend suitable specifications based on your project.
Can you provide customized sizes?
Yes. We support roll width, roll length, and tensile strength.
Get a Factory Quote Today
Looking for a reliable HDPE uniaxial geogrid supplier for your project?
Our team can help you select the right product and provide competitive factory pricing.
Send us your inquiry today to receive:
Product specifications
Technical support
Best factory quotation
Contact us now to get a quick quote
